121.1 | Painting hook C-shape | Square | Flat

Product Features

Material: S235 JR steel
Design: C-shape, square, flat
Wire diameter: 1.00 mm to 12 mm
Length: 50 mm to 1500 mm
Leg widths: available from 20 to 30 mm

Upon request, we can also supply painting hooks made from other materials (including spring steel and stainless steel) or in custom lengths and wire diameters (up to 30 mm).

Article No.	Units/Package	Stock	L X Ø in mm	Legs A/B in mm
121.100110005000K	5000	105000	50 x 1,10	20/20
121.100110010000K	4000	24000	100 x 1,10	20/20
121.100150005000K	5000	129998	50 x 1,50	20/20
121.100150010000K	2000	247500	100 x 1,50	20/20
121.100150020000K	1000	12000	200 x 1,50	20/20
121.100150025000K	2000	4500	250 x 1,50	20/20
121.100150050000K	2000	19790	500 x 1,50	20/20
121.100150070000K	2000	42500	700 x 1,50	20/20
121.100200005000K	4000	161500	50 x 2,00	20/20
121.100200006000K	4000	262000	60 x 2,00	20/20
121.100200007500K	2000	254000	75 x 2,00	20/20
121.100200010000K	2000	422989	100 x 2,00	20/20
121.100200012000K	1000	54000	120 x 2,00	20/20
121.100200015000K	1000	275900	150 x 2,00	20/20
121.100200020000K	600	185600	200 x 2,00	20/20
121.100200025000K	500	34088	250 x 2,00	20/20
121.100200030000K	800	64000	300 x 2,00	20/20
121.100200035000K	1000	3200	350 x 2,00	20/20
121.100200040000K	800	21600	400 x 2,00	20/20
121.100200045000K	1000	55000	450 x 2,00	20/20
121.100200050000K	1000	22185	500 x 2,00	20/20
121.100200060000K	1000	30000	600 x 2,00	20/20
121.100200070000K	1000	28500	700 x 2,00	20/20
121.100200080000K	1000	7400	800 x 2,00	20/20
121.100250010000K	2000	86497	100 x 2,50	20/20
121.100250070000K	1000	54000	700 x 2,50	20/20
121.100300005000K	2000	36000	50 x 3,00	20/20
121.100300006000K	1500	43500	60 x 3,00	20/20
121.100300007500K	1000	123300	75 x 3,00	20/20
121.100300010000K	1000	857990	100 x 3,00	20/20
121.100300012000K	1000	39000	120 x 3,00	20/20
121.100300015000K	500	213750	150 x 3,00	20/20
121.100300020000K	400	210800	200 x 3,00	20/20
121.100300025000K	400	82000	250 x 3,00	20/20
121.100300030000K	400	181290	300 x 3,00	20/20
121.100300035000K	400	32500	350 x 3,00	20/20
121.100300040000K	500	69500	400 x 3,00	20/20
121.100300045000K	500	18798	450 x 3,00	20/20
121.100300050000K	500	33000	500 x 3,00	20/20
121.100300055000K	500	23200	550 x 3,00	20/20
121.100300060000K	400	28000	600 x 3,00	20/20
121.100300070000K	800	10400	700 x 3,00	20/20
121.100300080000K	600	9600	800 x 3,00	20/20
121.100300090000K	500	8000	900 x 3,00	20/20
121.100300100000K	300	1500	1000 x 3,00	20/20
121.100400007500K	1200	16800	75 x 4,00	20/20
121.100400010000K	800	170380	100 x 4,00	20/20
121.100400015000K	500	94000	150 x 4,00	20/20
121.100400020000K	250	88500	200 x 4,00	20/20
121.100400025000K	250	26500	250 x 4,00	20/20
121.100400030000K	250	45000	300 x 4,00	20/20
121.100400035000K	250	79500	350 x 4,00	20/20
121.100400040000K	250	25750	400 x 4,00	20/20
121.100400045000K	400	15000	450 x 4,00	20/20
121.100400050000K	250	34500	500 x 4,00	20/20
121.100400060000K	250	750	600 x 4,00	20/20
121.100400070000K	500	2500	700 x 4,00	20/20
121.100400080000K	250	2400	800 x 4,00	20/20
121.100400090000K	500	5000	900 x 4,00	20/20
121.100500010000K	500	11500	100 x 5,00	22/22
121.100500015000K	350	5550	150 x 5,00	22/22
121.100500020000K	200	12196	200 x 5,00	22/22
121.100500025000K	250	0	250 x 5,00	22/22
121.100500030000K	250	5996	300 x 5,00	22/22
121.100500040000K	250	2250	400 x 5,00	22/22
121.100500050000K	250	4250	500 x 5,00	22/22
121.100600007500K	500	3500	75 x 6,00	22/22
121.100600010000K	500	17000	100 x 6,00	22/22
121.100600015000K	300	0	150 x 6,00	22/22
121.100600020000K	250	6486	200 x 6,00	22/22
121.100600025000K	250	2250	250 x 6,00	22/22
121.100600030000K	250	5089	300 x 6,00	22/22
121.100600035000K	250	2000	350 x 6,00	20/20
121.100600040000K	200	172	400 x 6,00	22/22
121.100600050000K	200	1000	500 x 6,00	22/22
121.100600060000K	200	0	600 x 6,00	22/22
121.100600070000K	150	900	700 x 6,00	22/22
121.100800010000K	300	5400	100 x 8,00	24/24
121.100800015000K	200	3190	150 x 8,00	24/24
121.100800020000K	200	4503	200 x 8,00	24/24
121.100800030000K	100	1495	300 x 8,00	24/24
121.100800040000K	100	588	400 x 8,00	24/24
121.100800050000K	100	7747	500 x 8,00	24/24
121.100800060000K	100	893	600 x 8,00	24/24
121.100800070000K	100	679	700 x 8,00	24/24
121.101000010000K	200	1200	100 x 10,00	30/30
121.101000015000K	100	650	150 x 10,00	30/30
121.101000020000K	100	709	200 x 10,00	30/30
121.101000025000K	100	900	250 x 10,00	30/30

Product Description

Our C-shaped painting hooks (square, flat-lying) are ideal for use in powder coating, wet painting, and cathodic electrocoating (KTL). They ensure that components are suspended securely and stably throughout the entire coating process. This version, featuring wider legs ranging from 20 to 30 mm, is ideal for applications requiring a more stable support for components. Depending on the version, both lightweight and heavier components can be securely supported. Manufactured from robust S235 JR steel, the painting hooks are designed for industrial use and are reusable multiple times. Alternative materials such as stainless steel or spring steel are available upon request.

Advantages of the painting hook

Secure and stable suspension of your components
Suitable for components of various weights, depending on the model selected
Durable and reusable
Available in many sizes and wire thicknesses as a standard product

Fast delivery

All catalog items are available at our warehouse in Bad Essen. Thanks to our efficient warehouse management, orders received by 1:00 PM can be shipped the same day. As a rule, delivery therefore takes place on the next business day.

Free Sample Order

You can order a free sample of any version of the product by clicking the icon in the product table. This allows you to test our paint hooks right at your location and see our quality for yourself. If you order only samples, there are no shipping costs.

How to Order Samples

1. Log in to our online store
2. Select the desired product
3. In the product table, you will find an additional sample icon next to the shopping cart icon
4. Clicking the sample icon adds the product as a sample to your shopping cart
5. You can then complete the order as usual.

Your Benefits with Emptmeyer

Stock items available immediately
Free samples with no shipping costs
Personal consultation from our sales representatives
Development and manufacturing of our paint hooks in Bad Essen

Custom Paint Hooks

Do you need a specific geometry or a custom solution? We are happy to manufacture custom paint hooks for you with a wire diameter of up to 30 mm and a total length of 1500 mm.

Discover our custom paint hooks in the EMPTMEYER plus section.
Request a custom solution now
