121.1 | Hooks C-form | square | 90° turned

Product Specifications

Material: S235 JR steel
Design: C-shape, square, 90° bend
Wire diameter: 1.50 mm to 8 mm
Length: 50 mm to 800 mm
Leg width: 20 mm to 24 mm

Upon request, we can also supply paint hooks made from other materials (including spring steel and stainless steel) or in custom lengths and wire diameters (up to 30 mm).

Article No.	Units/Package	Stock	L X Ø in mm	Leg A/B in mm
121.100150006090K	4000	185000	60 x 1.50	20/20
121.100150007590K	2000	68000	75 x 1.50	20/20
121.100150010090K	2000	51800	100 x 1.50	20/20
121.100150015090K	1000	211000	150 x 1.50	20/20
121.100150020090K	2100	149100	200 x 1.50	20/20
121.100200005090K	1500	30000	50 x 2.00	20/20
121.100200006090K	3000	21000	60 x 2.00	20/20
121.100200007590K	1000	173040	75 x 2.00	20/20
121.100200010090K	1000	164000	100 x 2.00	20/20
121.100200015090K	1200	156000	150 x 2.00	20/20
121.100200020090K	500	106050	200 x 2.00	20/20
121.100200025090K	250	24000	250 x 2.00	20/20
121.100200030090K	250	9750	300 x 2.00	20/20
121.100200035090K	500	0	350 x 2.00	20/20
121.100200040090K	500	207200	400 x 2.00	20/20
121.100200060090K	500	74500	600 x 2.00	20/20
121.100200070090K	1500	22500	700 x 2.00	20/20
121.100200080090K	1000	4647	800 x 2.00	20/20
121.100300006090K	1000	5970	60 x 3.00	20/20
121.100300007590K	600	22800	75 x 3.00	20/20
121.100300010090K	600	21100	100 x 3.00	20/20
121.100300015090K	600	97990	150 x 3.00	20/20
121.100300020090K	400	74200	200 x 3.00	20/20
121.100300025090K	700	33600	250 x 3.00	20/20
121.100300030090K	300	59100	300 x 3.00	20/20
121.100300035090K	400	5600	350 x 3.00	20/20
121.100300040090K	300	61800	400 x 3.00	20/20
121.100300045090K	400	10400	450 x 3.00	20/20
121.100300050090K	400	14400	500 x 3.00	20/20
121.100300060090K	400	20400	600 x 3.00	20/20
121.100300070090K	800	13600	700 x 3.00	20/20
121.100300080090K	600	1800	800 x 3.00	20/20
121.100400010090K	800	15025	100 x 4.00	20/20
121.100400015090K	250	7250	150 x 4.00	20/20
121.100400020090K	250	9750	200 x 4.00	20/20
121.100400025090K	250	0	250 x 4.00	20/20
121.100400030090K	250	6750	300 x 4.00	20/20
121.100400035090K	250	4100	350 x 4.00	20/20
121.100400040090K	400	4000	400 x 4.00	20/20
121.100400050090K	400	12000	500 x 4.00	20/20
121.100400060090K	400	8000	600 x 4.00	20/20
121.100400070090K	250	2500	700 x 4.00	20/20
121.100600010090K	500	3500	100 x 6.00	22/22
121.100600020090K	250	1240	200 x 6.00	22/22
121.100600030090K	250	2750	300 x 6.00	22/22
121.100800020090K	100	580	200 x 8.00	20/20
121.100800040090K	100	490	400 x 8.00	24/24

Product Description

Our C-shaped painting hooks (angular, 90° twisted) are ideal for applications requiring an angled component mounting. The twisted design allows for a different positioning of the component, making it particularly well-suited for complex geometries or special suspension scenarios. They are used in powder coating, wet painting, and cathodic electrocoating (KTL), among other applications, and ensure secure and stable suspension throughout the entire coating process. Manufactured from robust S235 JR steel, the painting hooks are designed for industrial use and are reusable multiple times. Alternative materials such as stainless steel or spring steel are available upon request.

Advantages of the painting hook

90° angled design for flexible component positioning
secure and stable suspension of your components
suitable for components of varying weights, depending on the selected model
durable and reusable
available in many sizes and wire thicknesses as a standard product

Fast delivery

All catalog items are available in our warehouse in Bad Essen. Thanks to our efficient warehouse management, orders received by 1:00 PM can be shipped the same day. As a rule, delivery therefore takes place as early as the next business day.

Free Sample Order

You can order a free sample of any version of the product by clicking the icon in the product table. This allows you to test our paint hooks right at your location and see our quality for yourself. If you order only samples, there are no shipping costs.

How to order a sample

Log in to our online store
Select the desired product
In the product table, you will find a sample icon next to the shopping cart icon
Clicking the sample icon adds the product to your shopping cart as a sample
You can then complete the order as usual.

Your Benefits with Emptmeyer

Stock items available immediately
Free samples with no shipping costs
Personal consultation from our sales representatives
Development and manufacturing of our paint hooks in Bad Essen

Custom Paint Hooks

Do you need a specific geometry or a custom solution?
We are happy to manufacture custom paint hooks for you with a wire diameter of up to 30 mm and a total length of 1500 mm.
Discover our custom paint hooks in the EMPTMEYER plus section
Request a custom solution now
