<tc>121.0 | Hook C-form | square | 90° turned</tc>

Product Specifications

Material: S235 JR steel
Design: C-shape, square, 90° bend
Wire diameter: 1.50 mm to 8 mm
Length: 50 mm to 800 mm
Leg width: 20 mm to 24 mm

Upon request, we can also supply paint hooks made from other materials (including spring steel and stainless steel) or in custom lengths and wire diameters (up to 30 mm).

Article No.	Units/Package	Stock	L x Ø in mm	Leg A/B in mm
121.000150005090K	2500	25000	50 x 1.50	11/11
121.000150007590K	4000	0	75 x 1.50	11/11
121.000150010090K	2000	76000	100 x 1.50	11/11
121.000150015090K	2000	12200	150 x 1.50	11/11
121.000200005090K	2500	5000	50 x 2.00	11/11
121.000200007590K	2000	114000	75 x 2.00	11/11
121.000200010090K	1000	6990	100 x 2.00	11/11
121.000200015090K	1000	36800	150 x 2.00	11/11
121.000200020090K	500	29600	200 x 2.00	11/11
121.000200030090K	500	4000	300 x 2.00	11/11
121.000300010090K	1000	2000	100 x 3.00	11/11
121.000300015090K	500	13200	150 x 3.00	11/11
121.000300020090K	600	2980	200 x 3.00	11/11
121.000300030090K	600	9600	300 x 3.00	11/11
121.000400010090K	500	500	100 x 4.00	11/11
121.000400015090K	500	1000	150 x 4.00	11/11

Product Description

Our C-shaped paint hooks (angular, 90° twisted, 11 mm leg size) are particularly suitable for applications with smaller and delicate components, where adapted component positioning is required at the same time.

The 90° twisted design allows for a changed orientation of the component. This enables optimal coating of even complex geometries or hard-to-reach areas.

The compact design also ensures space-saving loading and precise positioning of components in the coating process.

Made of robust S235 JR steel, the paint hooks are designed for industrial use and are reusable multiple times. Alternative materials such as stainless steel or spring steel are available upon request.

Advantages of the paint hook

90° twisted design for flexible component positioning
ideal for delicate and complex components
precise and stable component mounting
available as a standard product in many sizes and wire gauges
durable and reusable

Free sample order

You can order a free samplefor each variant of the item via the icon in the product table. This way, you can test our paint hook directly on site and convince yourself of our quality. If you only order samples, no shipping costs will be incurred.

How to order a sample

Log in to our online shop
Select the desired product
In the product table, next to the shopping cart icon, you will find an additional sample icon
By clicking on the sample icon, the product will be added to your shopping cart as a sample
You can then complete the order as usual.

Your advantages at Emptmeyer

immediately available stock goods
free samples without shipping costs
personal advice from our sales team
development and production of our paint hooks in Bad Essen

Custom paint hooks

Do you need a special geometry or a custom solution?

We are happy to manufacture individual paint hooks for you up to a wire diameter of 30 mm and a total length of 1500 mm.

Discover our individual paint hooks in the EMPTMEYER plus Request an individual solution
